DS-2XC6244G0-L

Omschrijving

Bullet Underwater Network Camera

  • Camera
  • Image Sensor1/1.8" Progressive Scan CMOS
  • Max. Resolution2688 × 1520
  • Min. IlluminationColor: 0.001 Lux @ (F1.0, AGC ON), B/W: 0 Lux with Light
  • Shutter Time1/3 s to 1/100,000 s
  • Lens
  • Lens TypeVarifocal lens, 3 to 9 mm
  • Focal Length & FOV3 to 9 mm, horizontal FOV 87° to 45.8°, vertical FOV 46° to 25.6°, diagonal FOV 104° to 52.4°
  • ApertureF1.0
  • DORI
  • DORI

    Wide: D: 55.2 m, O: 21.9 m, R: 11.0 m, I: 5.5 m

    Tele: D: 124.1 m, O: 49.3 m, R: 24.8 m, I: 12.4 m

  • Illuminator
  • Supplement Light TypeWhite Light
  • Supplement Light RangeUp to 10 m
  • Video
  • Main Stream

    50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

    60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

  • Sub-Stream

    50 Hz: 25 fps (640 × 480, 640 × 360)

    60 Hz: 30 fps (640 × 480, 640 × 360)

  • Third Stream

    50 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

    60 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

  • Video Compression

    Main stream: H.265+/H.265/H.264+/H.264

    Sub-stream: H.265/H.264/MJPEG

    Third stream: H.265/H.264

  • Video Bit Rate32 Kbps to 8 Mbps
  • H.264 TypeBaseline Profile/Main Profile/High Profile
  • H.265 TypeMain Profile
  • Scalable Video Coding (SVC)H.264 and H.265 encoding
  • Region Of Interest (ROI)5 fixed regions for each stream
  • Target CroppingYes
  • Network
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
  • Simultaneous Live ViewUp to 6 channels
  • APIOpen Network Video Interface, ISAPI, ISUP 5.0
  • User/Host

    Up to 32 users

    3 levels: Administrator, Operator and User

  • Network StorageNAS (NFS, SMB/CIFS), ANR
  • ClientiVMS-4200, Hik-Connect
  • Web Browser

    Plug-in required live view: IE10, IE11

    Local service: Chrome 57.0+, Firefox 52.0+

  • Image
  • Image Parameters SwitchYes
  • Image SettingsRotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser
  • Day/Night SwitchDay, Night, Auto, Schedule
  • Wide Dynamic Range (WDR)120 dB
  • Image EnhancementBLC, HLC, 3D DNR, defog
  • Interface
  • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
  • On-Board Storage

    Built-in memory card slot, support microSD/SDHC/SDXC card, up to 128 GB

    *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing.

  • Event
  • Basic EventMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
  • Smart Event

    Line crossing detection, intrusion detection, region entrance detection, region exiting detection

    Scene change detection, unattended baggage detection, object removal detection

  • General
  • Power

    36 VDC ± 20%, 0.6 A, max. 17 W, two-core terminal block

    PoE (802.3.at, Class 3, 42.5 V to 57 V), 0.45 A to 0.3 A, 17 W

  • MaterialSUS 316L Metal
  • Dimension210 mm × 210 mm × 205 mm (8.3" × 8.3" × 8.1")
  • Package Dimension700 mm × 530 mm × 365 mm (27.6" × 20.9" × 14.4")
  • Approx. 8.300 kg (18.38 lb.)



  • With Package WeightApprox. 12.300 kg (27.12 lb.)
  • Startup And Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 100% or less (non-condensing)
  • Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
  • General FunctionHeartbeat, password protection, privacy mask, watermark, IP address filter, mirror
  • Cable Length15 m (49.2 ft.) (included)
  • Approval
  • EMC

    FCC: FCC-SDoC (ANSI C63.4, FCC Part15 sub B)

    CE: CE-EMC (EN 50130-4:2011+A1:2014, EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013)

    RCM: AS/NZS 60950.1:2003 + Am1, Am2 and Am3, AS/NZS CISPR 32:2015

    IC: IC-VoC (ICES-003 Issue 7:2020)

    KC: KN 301489-1, KN 301489-17, RRA NOTICE 2017-14 (2017.12.05), RRA NOTICE 2017-19 (2017.12.28)

  • Safety

    UL: UL 62368-1: 2014, CAN/CSA C22.2 No. 62368:2014

    CB: IEC 62368-1:2014

    BIS: IS 13252 ( Part 1) 2010+A1:2013+A2:2015

    LOA: SANS IEC60950-1

  • ProtectionIP68 (IEC 60529-2013)

DS-2XC6244G0-L

Productformulier
Gratis afhalen in onze winkel(s)

€3.600,00 Incl. BTW

    • Vandaag verstuurd? Je hebt nog: Oct 26, 2025 17:00:00 +0100
    • Gratis verzending vanaf 99,-
    • Gratis retourneren binnen 30 dagen

    Omschrijving

    Bullet Underwater Network Camera

    • Camera
    • Image Sensor1/1.8" Progressive Scan CMOS
    • Max. Resolution2688 × 1520
    • Min. IlluminationColor: 0.001 Lux @ (F1.0, AGC ON), B/W: 0 Lux with Light
    • Shutter Time1/3 s to 1/100,000 s
    • Lens
    • Lens TypeVarifocal lens, 3 to 9 mm
    • Focal Length & FOV3 to 9 mm, horizontal FOV 87° to 45.8°, vertical FOV 46° to 25.6°, diagonal FOV 104° to 52.4°
    • ApertureF1.0
    • DORI
    • DORI

      Wide: D: 55.2 m, O: 21.9 m, R: 11.0 m, I: 5.5 m

      Tele: D: 124.1 m, O: 49.3 m, R: 24.8 m, I: 12.4 m

    • Illuminator
    • Supplement Light TypeWhite Light
    • Supplement Light RangeUp to 10 m
    • Video
    • Main Stream

      50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

      60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

    • Sub-Stream

      50 Hz: 25 fps (640 × 480, 640 × 360)

      60 Hz: 30 fps (640 × 480, 640 × 360)

    • Third Stream

      50 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

      60 Hz: 1 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

    • Video Compression

      Main stream: H.265+/H.265/H.264+/H.264

      Sub-stream: H.265/H.264/MJPEG

      Third stream: H.265/H.264

    • Video Bit Rate32 Kbps to 8 Mbps
    • H.264 TypeBaseline Profile/Main Profile/High Profile
    • H.265 TypeMain Profile
    • Scalable Video Coding (SVC)H.264 and H.265 encoding
    • Region Of Interest (ROI)5 fixed regions for each stream
    • Target CroppingYes
    • Network
    • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
    • Simultaneous Live ViewUp to 6 channels
    • APIOpen Network Video Interface, ISAPI, ISUP 5.0
    • User/Host

      Up to 32 users

      3 levels: Administrator, Operator and User

    • Network StorageNAS (NFS, SMB/CIFS), ANR
    • ClientiVMS-4200, Hik-Connect
    • Web Browser

      Plug-in required live view: IE10, IE11

      Local service: Chrome 57.0+, Firefox 52.0+

    • Image
    • Image Parameters SwitchYes
    • Image SettingsRotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser
    • Day/Night SwitchDay, Night, Auto, Schedule
    • Wide Dynamic Range (WDR)120 dB
    • Image EnhancementBLC, HLC, 3D DNR, defog
    • Interface
    • Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
    • On-Board Storage

      Built-in memory card slot, support microSD/SDHC/SDXC card, up to 128 GB

      *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing.

    • Event
    • Basic EventMotion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
    • Smart Event

      Line crossing detection, intrusion detection, region entrance detection, region exiting detection

      Scene change detection, unattended baggage detection, object removal detection

    • General
    • Power

      36 VDC ± 20%, 0.6 A, max. 17 W, two-core terminal block

      PoE (802.3.at, Class 3, 42.5 V to 57 V), 0.45 A to 0.3 A, 17 W

    • MaterialSUS 316L Metal
    • Dimension210 mm × 210 mm × 205 mm (8.3" × 8.3" × 8.1")
    • Package Dimension700 mm × 530 mm × 365 mm (27.6" × 20.9" × 14.4")
    • Approx. 8.300 kg (18.38 lb.)



    • With Package WeightApprox. 12.300 kg (27.12 lb.)
    • Startup And Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 100% or less (non-condensing)
    • Language33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
    • General FunctionHeartbeat, password protection, privacy mask, watermark, IP address filter, mirror
    • Cable Length15 m (49.2 ft.) (included)
    • Approval
    • EMC

      FCC: FCC-SDoC (ANSI C63.4, FCC Part15 sub B)

      CE: CE-EMC (EN 50130-4:2011+A1:2014, EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013)

      RCM: AS/NZS 60950.1:2003 + Am1, Am2 and Am3, AS/NZS CISPR 32:2015

      IC: IC-VoC (ICES-003 Issue 7:2020)

      KC: KN 301489-1, KN 301489-17, RRA NOTICE 2017-14 (2017.12.05), RRA NOTICE 2017-19 (2017.12.28)

    • Safety

      UL: UL 62368-1: 2014, CAN/CSA C22.2 No. 62368:2014

      CB: IEC 62368-1:2014

      BIS: IS 13252 ( Part 1) 2010+A1:2013+A2:2015

      LOA: SANS IEC60950-1

    • ProtectionIP68 (IEC 60529-2013)
