| Model: Reolink G330 |
| Video & Audio |
Sensor |
1/2.7" CMOS Sensor |
| Video Resolutie |
2560 x 1440 (4MP) @ 15 frames/sec |
| Video format |
H.265 |
| Kijkhoek |
Vaste lens, 125° diagonaal, 105° horizontaal, 55° verticaal |
| Nachtzicht |
Tot 10 meter (LED: 6st/14mil/850nm) |
| Frame rate |
Main stream: 10fps-15fps (default 15fps) Sub stream: 10fps-15fps (default 15fps) |
| Code rate |
Main stream: 1024Kbps-4096Kbps (default 3072Kbps) Sub stream: 64Kbps-672Kbps (default 672Kbps) |
| Audio |
Tweeweg audio |
PIR Detectie & Notificatie
|
Slim alarm |
PIR detectie/persoonsdetectie/voertuigdetectie/dierdetectie |
| PIR Detectie afstand |
Aanpasbaar tot 10 meter |
| PIR Detectie hoek |
120° horizontaal |
| Time lapse |
√ |
| Opnemen |
Bewegings-geactiveerd |
| Cloud opslag |
Ondersteunt Reolink Cloud (check beschikbaarheid) |
| SmartHome compatibel |
Google Assistant, Alexa |
| 3G & 4G bandbreedte |
Frequency bands |
Europa: LTE FDD: B1/B3/B7/B8/B20/B28A WCDMA: B1/B8 |
| Stroom |
Batterij |
28Wh oplaadbare batterij (levensduur afhankelijk van instellingen, gebruik & temperatuur) |
| Zonnepaneel |
Kan gekoppeld worden aan Reolink Solar Panel 2 (6W) |
Interface
|
SD kaartslot |
Ondersteuning tot 128GB micro SD kaart |
| Stroompoort |
USB type-C poort |
| SIM-kaartslot |
Nano |
| Resetknop |
√ |
| Audio in/uit |
Ingebouwde mic & speaker |
Software
|
OS |
PC: Windows, Mac OS; Smartphone: iOS, Android |
| Protocols |
SSL, TCP/IP, UDP, UPNP, SMTP, NTP, P2P |
| Gebruikers |
Max 12 gelijktijdige video streams (2 main & 10 sub streams) |
| Werkomgeving |
Bedrijfstemperatuur |
-10° ~ 55° C |
| Bedrijfs luchtvochtigheid |
20% ~ 85% |
| Waterresistent |
IP65 |
| Afmeting & gewicht |
Afmeting |
Φ75 x 194 mm |
| Gewicht (incl batterij) |
450 gr |
