Description
The Smart Plug can be controlled remotely via the mobile app, turn on and off on a schedule, and set to activate automatically when alarms are triggered or when the system is armed or disarmed.
- two-way RF communication.
- Shows the status with an LED indicator.
- Supports cloud updates and automatic recovery after a failed update.
- Provides protection against overcurrent, overvoltage and overheating.
- Measure the voltage, current and temperature.
Specifications:
-
Gate: Relay output, 1 port, NO/NC (100–240 VAC, max. 16 A)
-
Wireless:
- Indicator light, 1 indicator light, displays multiple statuses:
- Flashing green: pairing
- Solid green: circuit closed
- Light off: circuit open
-
Remote Update: Supports cloud update
-
Button: 1 button, performs multiple operations (open/close the circuit, reset to factory settings and pairing)
-
Signal strength: Supports detecting signal strength
-
Frequency range: 868-868.6MHz
-
Communication distance: In an open environment: 1,600 m (5,249.34 ft)
-
Maximum Power: 865-868.6 MHz @ 16.15 dBm
-
Communication mechanism: Two-way communication
-
Encryption: AES-128
-
Frequency hopping: Yes
General
-
Operating temperature: Indoor: –10 °C to +55 °C (+14 °F to +131 °F)
-
Operating humidity: 10%–90% (RH), non-condensing
-
Storage temperature: –10 °C to +55 °C (+14 °F to +131 °F)
-
Storage humidity: 10%–90% (RH), non-condensing
-
Power source: 100–240 VAC, 50/60 Hz
-
Product dimensions: 52mm × 52mm × 82mm (2.05" × 2.05" × 8.32")
-
Installation: With socket/2-pin
-
Net weight: 83g (0.18lb)
-
Power consumption: 0.3 W
Certifications
- CE
Housing material
- PC
Data monitoring
-
Data monitoring: Yes
-
Data type: Current, voltage, temperature
-
Accuracy: Protection range: 0 A–16 A, measurement accuracy: level 1.0 and above.
