JA-115E-GR, Wired control panel with keyboard, LCD and RFID reader

Name: JA-115E-GR, Wired control panel with keyboard, LCD and RFID reader
Brand: Jablotron
SKU: JA115EGR
Price: 216.65 EUR

Description

JA-115E-GR, Wired control panel with keyboard, LCD and RFID reader

The keyboard is part of the JABLOTRON system. It
serves for control and indication of the current system status.
It is equipped with four segments. The descriptions of this will be
displayed on the LCD screen. The device must be
installed by a trained technician with a valid certificate
issued by an authorized distributor. The keyboard
is compatible with the following keypads JA-102K, JA-103K and
JA-107K.

Specifications:

Type of control device	b
Power supply from control panel bus	12V DC (8-15V)
Power consumption in standby mode	18mA
Power consumption for cable selection	150mA
RFID frequency	125kHz
Maximum RFID magnetic field strength	-5.4 dBμA/m (measured at 10 m)
Dimensions	110 x 136 x 33mm
Weight	285g
Classification	Security class 2/Environmental class II according to EN 50131-1
General environment	General
Operating temperature range	-10 °C to +40 °C
Average operational humidity	75% RH, non-condensing
Certification body	Trezor Test s.r.o. (no. 3025)
In accordance with	ETSI EN 300 330, EN 50130-4, EN 55032, EN IEC 62368-1, EN IEC 63000, EN 50131-1, EN 50131-3
Can be operated according to	ERC REC 70-03
Recommended screw	4 x ø 3.5 x 40 mm (semi-circular head)

JA-115E-GR, Wired control panel with keyboard, LCD and RFID reader

Product form

In stock, delivery time 1 to 3 working days

€216,65 Incl. VAT

Free shipping from €99

Free returns within 30 days

Description

JA-115E-GR, Wired control panel with keyboard, LCD and RFID reader

The keyboard is part of the JABLOTRON system. It
serves for control and indication of the current system status.
It is equipped with four segments. The descriptions of this will be
displayed on the LCD screen. The device must be
installed by a trained technician with a valid certificate
issued by an authorized distributor. The keyboard
is compatible with the following keypads JA-102K, JA-103K and
JA-107K.

Specifications:

Type of control device	b
Power supply from control panel bus	12V DC (8-15V)
Power consumption in standby mode	18mA
Power consumption for cable selection	150mA
RFID frequency	125kHz
Maximum RFID magnetic field strength	-5.4 dBμA/m (measured at 10 m)
Dimensions	110 x 136 x 33mm
Weight	285g
Classification	Security class 2/Environmental class II according to EN 50131-1
General environment	General
Operating temperature range	-10 °C to +40 °C
Average operational humidity	75% RH, non-condensing
Certification body	Trezor Test s.r.o. (no. 3025)
In accordance with	ETSI EN 300 330, EN 50130-4, EN 55032, EN IEC 62368-1, EN IEC 63000, EN 50131-1, EN 50131-3
Can be operated according to	ERC REC 70-03
Recommended screw	4 x ø 3.5 x 40 mm (semi-circular head)
