Description
Jablotron JA-123E-NFC BUS outdoor access module with RFID and keypad
The Jablotron JA-123E-NFC BUS outdoor access module with RFID 13.56Mhz (Mifare) and keyboard can be used to activate a PG output with which you can use local control of, for example, an electric lock or the security system. This module works with the JA-103 and JA-107 control panel.
Main features:
- Control panel bus power, 12 V, DC (8-15 V)
- Quiescent current consumption 15mA
- Maximum power consumption 80mA
- Control device type 13.56 MHz
- Maximum RFID magnetic field strength 10.37 dBuA/m (3 m)
- Compatible RFID card NFC, Mifare® Classic, Mifare® DESFire® 4, 7-byte UID
- Dimensions 46x151.5x25mm
- Weight 196 grams
- Length of the connection cable 3.0 meters
- Operating temperature range -25 °C to +60 °C
- Relative humidity 75% without condensation
- Environment according to IV. Outside general
- Classification Grade 2 according to EN 50131-1, EN 50131-3
- Additionally in accordance with ETSI EN 300330, EN 50130-4, EN 55032, EN 62368-1, EN IEC 63000
